8MP 4K IP Camera Indoor H.265 Onvif Bullet CCTV Mini BOX Square Micro Audio 4MP POE Video Surveillance Kamera
8MP 4K IP Camera Indoor H.265 Onvif Bullet CCTV Mini BOX Square Micro Audio 4MP POE Video Surveillance Kamera
Couldn't load pickup availability
SPECIFICATIONS
Brand Name: HQCAM
Type: ip camera
Supported Operating Systems: Windows XP
Supported Operating Systems: Windows 7
Supported Operating Systems: Windows 8
High Definition: 8.0 Megapixels
Lens (mm): 3.6mm
Lens (mm): 6mm
Lens (mm): 8mm
Lens (mm): 2.8mm
Lens (mm): 12mm
Style: Bullet Camera
Certification: CE
Connectivity: IP/Network Wired
Origin: Mainland China
Installation: Embedded
Wall Bracket: Side
Color: WHITE
Sensor: CMOS
Megapixels: 8MP
Sensor Brand: Sony
Special Features: Waterproof / Weatherproof
Storage: None
Alarm Action: FTP Photo
Alarm Action: Local Alarm
Video Compression Format: H.264
Video Compression Format: H.265
Power Supply: With POE
TF Card: None
is_customized: Yes
Viewing Angle : 130°
Technology: INFRARed
Network Interface: RJ-45 10/100Mb Ethernet Slot
Audio Output: None
Power Consumption(W): 12V2A(Not included Power Supply )
Minimum Illumination(Lux): 0.001Lux F1.2
IR Distance(m): NA
Power Supply(V): DC12V
Model Number: 8mp ip camera
Housing Material: Aluminum-alloy Metal
Features: Vandal-Proof ,Waterproof
Optional POE: 48V
Compression Forma: Advanced H.265/H.264 video compression
Style1: Ip Camera
Style2: Cctv Camera
Style3: Security Camera
Style4: Surveillance Camera
Style5: Video Surveillance
Style6: Surveillance
Style7: ip camera poe
4K 8MP is clearer
Immersive 2MP/5MP Super HD
An Incredible 8MP 4K Super HD IP Camera
With a high resolution of 8megapixels (3840 x 2160), this 8MP HD IP surveillance camera is able to capture videos in 3840p HD quality. It is a huge advancement compared to 720p HD or 1080p Full HD. you never miss a single detail of your loved ones. which enables you to see all objects very clearly.
K NVR
Please Use 4K NVR Get 4K HD
If You DVR is 5MP/4MP/1080P, You Only Get 5MP/4MP/1080P. so You need to confirm your NVR!
If there are any problems during use,Please contact us, we will be within 8 hours, quick reply, to provide you with quality after-sales Service!
Key features(Super 8MP is not a Sony sensor):
1.1/2.8" 800W SONY 415 sensor, Hays 3516AV300 chip
2. Support H.265/H.264;
3. Support three code stream, the main code stream:
4 k (3840 * 2160) / 4 m (2560 * 1440) (2304 * 1296) / 2/3 m m (1920 * 1080);
Auxiliary code stream 1:720P(1280*720)/448P(800*448)/704*576/640*360/352*288; Auxiliary stream two:
360/352 * 640 * 288;
4. Support digital wide dynamic, 3D noise reduction, backlight compensation, automatic white balance, suitable for different monitoring environment;
5. Support ONVIF protocol, access to third-party NVR;
6.ICR filter switching function, 24 hours monitoring;
7. Supports screen blocking, 4 blocks of blocking area can be set;
8. Support audio input to realize perfect monitoring of video recording;
9. Support movement detection, the alarm of movement detection will automatically send email reminder;
10. Support OSD location setting and network timing;
11. Support mobile phone monitoring (IOS, Android), Web terminal,
12. Support automatic maintenance function;
13. Support POE power supply (optional);
14. Support FTP function;
15 support the infinite infrared light, the infinite white light
Specification:
| Models |
|
|
|
|
4K Ultra low-illumination HD Network Camera Module |
|
| Image Sensor |
1/2.8" 8.0MP CMOS Sony IMX415 Sensor HI3516 |
|
| Min. Illumination |
Color:0.01Lux |
|
| S/N Ratio |
≥72dB |
|
| Wide Dynamic Range |
Digital WDR |
|
| Digital noise Reduction |
DNR,3DNR |
|
| Exposure Mode |
Auto/Manual/shutter mode(shutter range variable) |
|
| White Balance |
Auto/Manual /ATW/Indoor/Outdoor/Daylight lamp/Sodium lamp |
|
| Day & Night |
Day / Night / External control(IR Cut Filter) |
|
| Video Compression |
H.265/H.264 Main Profile |
|
| Audio Compression |
G.711/G.711.A |
|
| Max. Image Resolution |
3840*2160 @ 20fps |
|
| Image Resolution |
Main stream |
3840*2160@1-20fps,3072*2048/2592*1944/2560*1440/2304*1296/2048*1536/1080P/960P/720P@1-30fps |
|
|
Sub-stream |
720*480/D1/VGA/640*360/CIF@1-30fps |
| Streams |
Dual streams |
|
| Bitrate |
CBR/VBR bitrate:50Kbps~12Mbps variable |
|
| Simultaneous Live View |
Main stream Up to 5,Sub-stream Up to 5 |
|
| OSD |
Support OSD setting, support free transfer position |
|
| Motion detect |
Support |
|
| IO |
Unsupport |
|
| P2P |
Android,IOS |
|
| Protocols |
HTTP/NTP/DHCP/UDNP/RTSP/P2P/ONVIF |
|
| Onvif |
Onvif 2.4 Hikvision Agreement |
|
| Network |
10/100M Base-TX Ethernet, RJ45 Connector |
|
| Store |
Unsupport |
|
| Protection Level |
TVS 6,000V lightning protection |
|
| Power Supply |
12VDC at 0.2A |
|
| Dimensions |
|
|
| Working Temperature |
-30°C ~65°C, Humidity≤90%RH(Unsupport-condensing) |
|
POE version
IEEE802.3af/at
12V power supply version
